Boiler modulation is a boiler’s ability to reduce its heat output when your home doesn’t need its full power. Instead of always firing at maximum output and switching off when enough heat has been produced, a modulating boiler can reduce its firing rate to better match demand.
This can help a boiler run for longer periods at a lower output, reduce unnecessary on-and-off cycling and potentially improve efficiency. However, a large modulation ratio isn’t automatically better. The boiler’s actual minimum central-heating output is often the more useful figure to consider.
How does boiler modulation work?
Your home’s heating requirements aren’t constant.
A boiler may need to produce considerably more heat on a freezing winter morning than during mild autumn weather. Demand also falls as your home approaches the temperature set on the thermostat.
A modulating boiler can respond by adjusting its burner output.
For example, imagine a boiler capable of operating anywhere between 3kW and 30kW. When the house needs a lot of heat, it can operate towards the top of that range. As demand falls, it can reduce its output.
If the property requires only 4kW at a particular moment, the boiler may therefore be able to operate at approximately that level rather than continuing to produce 30kW and repeatedly switching off.
What is a boiler modulation ratio?
The modulation ratio describes the relationship between the boiler’s maximum and minimum output.
For example, a boiler with a maximum output of 30kW and a 10:1 modulation ratio can theoretically reduce its output to around 3kW.
The calculation is:
Maximum output ÷ modulation ratio = minimum output
Here are some examples:
| Maximum output | Modulation ratio | Approx. minimum output |
| 24kW | 3:1 | 8kW |
| 24kW | 5:1 | 4.8kW |
| 24kW | 6:1 | 4kW |
| 24kW | 10:1 | 2.4kW |
| 30kW | 10:1 | 3kW |
Manufacturer specifications don’t always present modulation in exactly the same way, so check whether the figures refer specifically to central heating when comparing boilers.
Is a 10:1 modulation ratio better than 5:1?
If everything else were equal, a 10:1 modulation ratio would allow a boiler to reduce its output further than a 5:1 ratio.
For a 30kW boiler:
- 5:1 modulation gives a minimum output of approximately 6kW.
- 10:1 modulation gives a minimum output of approximately 3kW.
The second boiler can therefore match lower heating demands without switching off.
But comparing modulation ratios alone can be misleading.
Consider two different boilers:
| Boiler | Maximum output | Modulation ratio | Minimum output |
| Boiler A | 30kW | 10:1 | 3kW |
| Boiler B | 20kW | 5:1 | 4kW |
Boiler A has twice the modulation ratio, but its minimum output is only 1kW lower.
This is why the minimum central-heating output is an important specification when choosing a boiler.
Why does minimum boiler output matter?
A home’s heat demand can become quite low during mild weather or when only a small amount of additional heat is required.
Suppose your home currently loses heat at a rate of 3kW.
A boiler capable of reducing its output to 3kW can potentially run steadily while providing approximately the amount of heat required.
If another boiler can only reduce its output to 6kW, it will be producing heat faster than the property needs it. Eventually, the boiler will have to stop firing and restart when more heat is required.
This is known as cycling.
A lower minimum output can therefore be particularly useful when the home’s heating demand is substantially below the boiler’s maximum output.
What does boiler modulation have to do with cycling?
Some cycling is normal. Your boiler isn’t supposed to fire continuously regardless of demand.
Problems can arise when it repeatedly fires for short periods because its minimum output is higher than the amount of heat the system can use.
This is sometimes called short cycling.
Each cycle involves the boiler firing, stopping and later restarting. A boiler capable of reducing its output further may be able to run for longer at a lower firing rate instead.
Modulation isn’t the only factor that affects cycling. Boiler sizing, thermostat settings, radiator capacity, system water volume, flow temperature and heating controls can all influence how frequently a boiler switches on and off.
Does boiler modulation improve efficiency?
Yes. Modulation allows the boiler to reduce its output when less heat is needed. This can reduce unnecessary cycling and help the boiler operate more efficiently.
However, a wider modulation range doesn’t automatically mean lower gas consumption. Boiler sizing, controls and heating demand also affect efficiency.
What’s the difference between modulation and condensing?
Modulation changes how much heat the boiler produces, while condensing recovers additional heat from its combustion gases.
The two can work together. Lower output can help a boiler operate with lower water temperatures, creating better conditions for efficient condensing operation.
However, simply buying a boiler with a wide modulation range doesn’t guarantee lower bills. The heating system and controls also need to allow the boiler to operate effectively.
Boiler modulation vs modulating heating controls
A modulating boiler and modulating heating controls are related, but they’re not the same thing.
Boiler modulation refers to the appliance’s ability to vary its output. A boiler might, for example, be physically capable of operating between 3kW and 30kW.
Modulating controls communicate changing heat requirements to a compatible boiler rather than providing only a basic on/off instruction.
A traditional thermostat essentially tells the heating system that heat is or isn’t required. A compatible modulating control can provide more information about the level of demand.
Two common approaches are:
Load compensation: adjusts the boiler’s operation according to the difference between the actual room temperature and the desired temperature.
Weather compensation: adjusts heating operation according to outdoor temperature.
OpenTherm is one communication protocol that can allow compatible boilers and heating controls to exchange this type of information. Compatibility varies between products, so an OpenTherm thermostat shouldn’t be assumed to provide full modulation with every boiler.
What is a good boiler modulation ratio?
There’s no single ratio that’s ideal for every property.
A wider modulation range is generally useful because it gives the boiler greater ability to reduce its output as heating demand falls. Modern boilers may offer ratios of around 5:1, 10:1 or even wider.
However, don’t choose a boiler simply because it advertises the largest modulation ratio.
Instead, consider:
- Minimum central-heating output
- Maximum central-heating output
- Your property’s calculated heat loss
- Compatibility with modulating controls
- Radiator or emitter sizing
- The boiler’s ability to operate efficiently at lower loads
This is particularly important with combi boilers.
A combi may need a relatively high maximum output to produce enough instantaneous hot water for showers and taps. That doesn’t necessarily mean your home needs anywhere near that output for central heating.
For this reason, look specifically at the boiler’s central-heating output range rather than assuming the headline kW figure tells you everything.
Should you replace a boiler for a better modulation ratio?
Usually, modulation ratio alone isn’t a good reason to replace an otherwise suitable and reliable boiler.
If you’re already replacing the boiler, however, minimum output is worth considering alongside efficiency, hot-water performance, warranty, controls and appropriate sizing.
This can be especially relevant in a well-insulated home with relatively low heat demand. A boiler with a high minimum output may have more difficulty matching that demand during milder weather.
An installer can calculate the property’s heat loss and use this alongside the boiler’s specifications to determine an appropriate output range.
Frequently asked questions
Is a higher boiler modulation ratio better?
A higher ratio generally means the boiler can reduce its output further relative to its maximum. However, compare the actual minimum central-heating outputs rather than relying on the ratio alone.
What does 1:10 modulation mean?
A 1:10 or 10:1 modulation ratio means the boiler can reduce its output to approximately one-tenth of its maximum. A 30kW boiler with a 10:1 range could therefore have a minimum output of around 3kW.
Does modulation stop a boiler from cycling?
It can reduce cycling by allowing the boiler to match lower heating demands, but it can’t necessarily eliminate it. Once heat demand falls below the boiler’s minimum output, the boiler may still need to switch off.
Do all modern boilers modulate?
Modern gas boilers commonly have some ability to vary their output, but the available modulation range differs considerably between models. How effectively that capability is used also depends on the controls and heating system.
Is modulation ratio important for a combi boiler?
Yes, but look at both ends of the output range. A combi may require high maximum output for hot water while the home’s central-heating demand is much lower. A low minimum central-heating output can therefore be particularly useful.
